UNCLASSIFIED
PE 0604757N: Ship Self Def (Engage: Soft Kill/EW)
UNCLASSIFIED
Navy Page 1 of 37 R-1 Line #144
Exhibit R-2, RDT&E Budget Item Justification: PB2021Navy
Date: February 2020
Appropriation/Budget Activity
1319: Research, Development, Test & Evaluation, Navy / BA 5: System
Development & Demonstration (SDD)
R-1 Program Element (Number/Name)
PE 0604757N / Ship Self Def (Engage: Soft Kill/EW)
COST ($ in Millions)
Prior
Years FY 2019 FY 2020
FY 2021
Base
FY 2021
OCO
FY 2021
Total FY 2022 FY 2023 FY 2024 FY 2025
Cost To
Complete
Total
Cost
Total Program Element
574.782 124.769 95.282 89.373 - 89.373 40.516 41.001 36.278 36.995 Continuing Continuing
0954: Shipboard EW
Improvement Program
44.007 10.913 15.865 16.375 - 16.375 16.448 16.735 17.061 17.392 Continuing Continuing
2190: NULKA Decoy
43.427 3.805 5.090 5.291 - 5.291 6.962 7.036 7.179 7.322 Continuing Continuing
3316: Advanced Offboard EW
160.758 70.691 52.198 44.814 - 44.814 10.203 10.283 4.960 5.060 Continuing Continuing
3321: SEWIP Block 3
326.590 39.360 22.129 22.893 - 22.893 6.903 6.947 7.078 7.221 Continuing Continuing
A. Mission Description and Budget Item Justification
0954 - The Surface Electronic Warfare Improvement Program (SEWIP) is segmented into Block 1A, Block 1B, Block 2, Block 3 and Soft Kill Coordination System
(SKCS). Block 1A upgraded the AN/SLQ-32 pulse-processing computers and the display consoles allowing the system to more quickly identify threats and better
display the information to the operator. Block 1B added adjunct sensors for special signal intercept, including Specific Emitter Identification (SEI), and High Gain High
Sensitivity (HGHS) (Block 1B3), a critical improvement for the threat correlation, situational awareness, and extending the battle space. Block 2 enhanced Surface
Electronic Warfare (EW) and provided improved Anti-Ship Missile Defense (ASMD) and Situational Awareness (SA) through an improved Electronic Support (ES)
receiver, antenna, and combat system interface. The addition of Block 2 to Block 1B3 forms the AN/SLQ-32 (V)6. Block 3 will provide an enhanced Electronic Attack
(EA) capability to improve ASMD and counter-targeting. The addition of Block 3 to AN/SLQ-32 (V)6 forms the AN/SLQ-32(V)7 system. EW Rapid Capability Insertion
Process (RCIP) identifies system and mission capability gaps by analyzing EW baseline and fleet requirements, prioritizes those gaps based on fleet input and critical
technology maturity, and develops upgrades to the AN/SLQ-32(V) product line to address those gaps. The SKCS will provide SK weapon coordination and enhanced
situational awareness to the AN/SLQ-32 (V)6 with EW/radar track association to support SK engagement decisions, including Radar Cued Engagements (RCE) and EA
with both onboard EA, provided by AN/SLQ-32 (V)7, and off-board EA. RCIP also integrates Future Naval Capability (FNC) programs into SEWIP.
2190 - The Offboard Active Decoy (NULKA) is a joint cooperative program between the United States and Australia that developed an active offboard decoy that utilizes
a broadband radio frequency repeater mounted atop a hovering rocket. NULKA counters a wide variety of present and future radar guided Anti-Ship Missiles (ASMs)
by radiating a large radar cross section while flying a ship-like trajectory. The United States developed the electronic payload and fire control system, while Australia
developed the hovering rocket. FY21 funding includes Decoy Launcher Processor (DLP) technology refresh to address obsolescence issues. This effort consists of
development of the Decoy Launch Message Convertor (DLMC) and delivery of Engineering Development Models (EDMs) to support Factory Qualification Testing (FQT)
and Environmental Qualification Testing (EQT) to improve employment of the NULKA system.
3316 - The Advanced Offboard EW (AOEW) program is for the development of long duration off-board decoys integrated with onboard systems for EW coordination to
counter identified EW gaps (additional details classified) in response to an urgent operational need from the Fleet that has been approved by the CNO for execution.
Currently no counter to the threat exists. In FY 2012, the program began with a Rapid Response Effort (RRE) which was completed in FY 2014. The RRE consisted of
the evaluation and integration of commercially available decoys. The Decoy Development Effort (DDE) consists of the development and evaluation of a long duration,
active electronic offboard decoy system (payload) integrated on an existing flight vehicle (MH-60R/MH-60S), integration with ship and air systems, and a government
Volume 3 - 1207
UNCLASSIFIED
PE 0604757N: Ship Self Def (Engage: Soft Kill/EW)
UNCLASSIFIED
Navy Page 2 of 37 R-1 Line #144
Exhibit R-2, RDT&E Budget Item Justification: PB2021Navy
Date: February 2020
Appropriation/Budget Activity
1319: Research, Development, Test & Evaluation, Navy / BA 5: System
Development & Demonstration (SDD)
R-1 Program Element (Number/Name)
PE 0604757N / Ship Self Def (Engage: Soft Kill/EW)
software development effort to integrate AOEW into the Soft Kill Coordination System (SKCS) to gain maximum effectiveness from the decoy through coordination with
an onboard system.
The DDE Preliminary Design contract was awarded Dec 2016 followed by a System Requirements Review (SRR)/System Functional Review (SFR) leading to a
Preliminary Development Review (PDR) in Sep 2017. The Engineering Manufacturing and Development (EMD) Option was awarded in Sep 2017. The program
schedule was revised to align with funding limitations in FY17 through FY20, however in FY21 the budget increases to support completion of critical technical tasking.
The Factory Qualification Test (FQT) will be completed on the Engineering Development Models (EDMs) to support completion and delivery of the Technical Data
Package (TDP) and developmental testing. As a result, developmental testing is scheduled to complete in FY22 and operational testing is scheduled to complete in
FY23. Operational test results (Initial Operational Test & Evaluation) is planned to support the Full Rate Production (FRP) decision scheduled for FY23.
NAVAIR Avionics Operating Program (AOP) software development and Flight Certification are required to support fielding of the AOEW decoy. The AOP software
supports integration of the AOEW decoy with the MH-60R/S airframe and is required for successful completion of Flight Certification. Flight Certification ensures
operational Safety of Flight and is critical to successful decoy fielding. NAVAIR Flight Certification will complete in FY22.
3321 - SEWIP Block 3 is developing an Electronic Attack (EA) capability improvement required for the AN/SLQ-32(V) system to keep pace with the threat. SEWIP Block
3 will provide the AN/SLQ-32(V)7 system for all surface ships (CVN, DDG, LHD) outfitted with the active variant of the AN/SLQ-32, mainly the (V)3 and (V)4, as well as
select new construction platforms.
The SEWIP Block 3 Acquisition leverages technology developed under the Office of Naval Research's (ONR) Integrated Topside (InTop) Science and Technology
(S&T) effort. SEWIP Block 3 will continue to expand the integrated shipboard combat system by providing a new integrated EA transmitter, array, and associated
EA techniques. The AN/SLQ-32(V)7 integrates the new EA countermeasure (SEWIP Block 3) with the AN/SLQ-32(V)6. The AN/SLQ-32(V)6 includes an Electronic
Support(ES) receiver (SEWIP Block 2), a High Gain High Sensitivity (HGHS) receiver (SEWIP Block 1B3), a Specific Emitter Identifier (SEI) receiver (SEWIP Block
1B2), display console, and backend electronics. SEWIP Block 3 includes a government software development and integration effort for a SoftKill Coordinator (SKC) to
manage EA engagements. SEWIP Block 3 is developing an Electronic Warfare Test Bed (EWTB) to validate system performance.
Volume 3 - 1208
UNCLASSIFIED
PE 0604757N: Ship Self Def (Engage: Soft Kill/EW)
UNCLASSIFIED
Navy Page 3 of 37 R-1 Line #144
Exhibit R-2, RDT&E Budget Item Justification: PB2021Navy
Date: February 2020
Appropriation/Budget Activity
1319: Research, Development, Test & Evaluation, Navy / BA 5: System
Development & Demonstration (SDD)
R-1 Program Element (Number/Name)
PE 0604757N / Ship Self Def (Engage: Soft Kill/EW)
B. Program Change Summary ($ in Millions)
FY 2019 FY 2020 FY 2021 Base FY 2021 OCO FY 2021 Total
Previous President's Budget 120.210 97.363 111.380 - 111.380
Current President's Budget 124.769 95.282 89.373 - 89.373
Total Adjustments 4.559 -2.081 -22.007 - -22.007
• Congressional General Reductions - -
• Congressional Directed Reductions - -2.081
• Congressional Rescissions - -
• Congressional Adds - -
• Congressional Directed Transfers - -
• Reprogrammings 7.123 0.000
• SBIR/STTR Transfer -2.563 0.000
• Program Adjustments 0.000 0.000 -22.274 - -22.274
• Rate/Misc Adjustments -0.001 0.000 0.267 - 0.267
Change Summary Explanation
FY2021 funding decrease of -$22.007M is due to an increase of $19.300 for the AOEW Program and other miscellaneous rate adjustments and a $41.574
reduction to SEWIP Block 4 for higher Navy priorities.
Volume 3 - 1209
UNCLASSIFIED
PE 0604757N: Ship Self Def (Engage: Soft Kill/EW)
UNCLASSIFIED
Navy Page 4 of 37 R-1 Line #144
Exhibit R-2A, RDT&E Project Justification: PB2021Navy
Date: February 2020
Appropriation/Budget Activity
1319 / 5
R-1 Program Element (Number/Name)
PE 0604757N / Ship Self Def (Engage: Soft
Kill/EW)
Project (Number/Name)
0954 / Shipboard EW Improvement Program
COST ($ in Millions)
Prior
Years FY 2019 FY 2020
FY 2021
Base
FY 2021
OCO
FY 2021
Total FY 2022 FY 2023 FY 2024 FY 2025
Cost To
Complete
Total
Cost
0954: Shipboard EW
Improvement Program
44.007 10.913 15.865 16.375 - 16.375 16.448 16.735 17.061 17.392 Continuing Continuing
Quantity of RDT&E Articles - - - - - - - - -
A. Mission Description and Budget Item Justification
0954 - The Surface Electronic Warfare Improvement Program (SEWIP) is segmented into Block 1A, Block 1B, Block 2, Block 3 and Soft Kill Coordination System
(SKCS). Block 1A upgraded the AN/SLQ-32 pulse-processing computers and the display consoles allowing the system to more quickly identify threats and better
display the information to the operator. Block 1B added adjunct sensors for special signal intercept, including Specific Emitter Identification (SEI), and High Gain High
Sensitivity (HGHS) (Block 1B3), a critical improvement for the threat correlation, situational awareness, and extending the battle space. Block 2 enhanced Surface
Electronic Warfare (EW) and provided improved Anti-Ship Missile Defense (ASMD) and situational awareness (SA) through an improved Electronic Support (ES)
receiver, antenna, and combat system interface. The addition of Block 2 to Block 1B3 forms the AN/SLQ-32 (V)6. Block 3 will provide an enhanced electronic attack
(EA) capability to improve ASMD and counter-targeting. The addition of Block 3 to AN/SLQ-32 (V)6 forms the AN/SLQ-32(V)7 system. EW Rapid Capability Insertion
Process (RCIP) identifies system and mission capability gaps by analyzing EW baseline and fleet requirements, prioritizes those gaps based on fleet input and critical
technology maturity, and develops upgrades to the AN/SLQ-32(V) product line to address those gaps. The SKCS will provide SK weapon coordination and enhanced
situational awareness to the AN/SLQ-32 (V)6 with EW/radar track association to support SK engagement decisions, including Radar Cued Engagements (RCE) and EA
with both onboard EA, provided by AN/SLQ-32 (V)7, and off-board EA. RCIP also integrates Future Naval Capability (FNC) programs into SEWIP.
B. Accomplishments/Planned Programs ($ in Millions, Article Quantities in Each)
FY 2019 FY 2020
FY 2021
Base
FY 2021
OCO
FY 2021
Total
Title: Electronic Warfare Rapid Capability Insertion Process (EW RCIP)
Articles:
FY 2020 Plans:
- Continue RCIP #4 SKCS efforts to address platform gaps for automatic and semi-automatic engagements
using Nulka decoys, onboard Electronic Attack (EA) (AN/SLQ-32 (V)7), and offboard EA systems; Initiate and
complete software development and system integration and testing activities for delivery of completed software
builds with capabilities including Hard Kill (HK)/Softkill (SK) coordination and enhanced capabilities for onboard
EA and offboard EA coordination, including automatic association and classification techniques; Continue
integration and testing activities in support of AEGIS ACB 16 baseline by completing element certification
in support of AEGIS ACB 16 Baseline 9.2.2 (Phase 2); Initiate integration and testing activities in support of
AEGIS ACB 20 (Baseline 10); Complete SKCS FQT for a software build in support of AN/SLQ-32(V)6 Formal
Qualification Testing (FQT), and continue to participate in system integration events with AN/SLQ-32(V)6, AN/
10.913
-
15.865
-
16.375
-
0.000
-
16.375
-
Volume 3 - 1210
UNCLASSIFIED
PE 0604757N: Ship Self Def (Engage: Soft Kill/EW)
UNCLASSIFIED
Navy Page 5 of 37 R-1 Line #144
Exhibit R-2A, RDT&E Project Justification: PB2021Navy
Date: February 2020
Appropriation/Budget Activity
1319 / 5
R-1 Program Element (Number/Name)
PE 0604757N / Ship Self Def (Engage: Soft
Kill/EW)
Project (Number/Name)
0954 / Shipboard EW Improvement Program
B. Accomplishments/Planned Programs ($ in Millions, Article Quantities in Each)
FY 2019 FY 2020
FY 2021
Base
FY 2021
OCO
FY 2021
Total
SLQ-32(V)7 and Offboard EW; Continue Ship Self Defense System (SSDS) ACB 20, Off-Shore Patrol Cutter
(OPC) and FFG(X) integration support efforts.
- Continue the transition of the Future Naval Capability (FNC) program, Softkill Performance and Real-Time
Assessment (SPARTA) into SKCS; Utilize developed algorithms to measure key features observed in Softkill
(SK) engagements and EA effectiveness and perform real-time assessment of SK performance; Complete the
development of improved fleet weapons coordination, informed HK/SK prioritization, weapons conservation,
and enhanced operator battlespace awareness by continuing to contribute integral feedback regarding non-
kinematic performance; Continue to develop and update the interface, architecture and algorithms required for
full transition into SKCS, taking into account ongoing SKCS build and capability completions; Continue to assess
the results and readiness of the SPARTA demonstration for transition into an SKCS Build.
- Complete RCIP #5 improvements to increase EW Tactical Simulation (TACSIM) capabilities to include system
integration with Ship Self Defense System (SSDS), SKCS, AEGIS ACB-16, and the onboard Surface Electronic
Warfare Team Trainer (SEWTT); Complete the TACSIM Phase 3 software delivery; Complete the TACSIM
Phase 4 effort, software integration and software delivery, including expansion of the Phase 3 technology to add
SLQ-32(V)7 support and upgrade SEWTT software to support countermeasure training.
- Continue SEWTT development of trainer enhancements including additional SKCS, Nulka, and Offboard EW
capabilities; Continue testing, integration, and documentation of the enhanced trainer and update associated
training materials.
- Complete the development phase, which started in FY19, of additional threat simulators for FNC Surveillance
and Response System (CESARS) program; Complete laboratory and at-sea test with actual systems and
simulator to validate CESARS design requirements; Continue development of SKCS pre-design material
to include CESARS capability; Continue to support the development and testing of the Multi-spectral EO/IR
Countermeasures against Advanced Threats (MEIRCAT) major deliverable component of CESARS; Continue
the interface, architecture, and ship integration for CESARS transition into the SEWIP program.
- Complete the design, development, and testing of AN/SLQ-32(V)6 and AN/SLQ-32(V)7 Electronic Support
(ES) system enhancements to provide advanced EW capabilities; Complete the development of techniques that
address new evolving threats, including the capabilities to sense dynamic radio frequency (RF) environments
and generate an improved response to enhance ship survivability; Continue development of the prototype to
test the techniques, and demonstrate the technique effectiveness and readiness for integration with the ship's
software.
- Initiate development of methods to improve radio frequency sensor planning for the Propagation Channel
Assessment and Prediction (PCAP) FNC, to allow for the ability to clearly convey to EW and other shipboard
personnel how the current and expected RF propagation conditions are affecting the ship's passive RF sensors;
Volume 3 - 1211
UNCLASSIFIED
PE 0604757N: Ship Self Def (Engage: Soft Kill/EW)
UNCLASSIFIED
Navy Page 6 of 37 R-1 Line #144
Exhibit R-2A, RDT&E Project Justification: PB2021Navy
Date: February 2020
Appropriation/Budget Activity
1319 / 5
R-1 Program Element (Number/Name)
PE 0604757N / Ship Self Def (Engage: Soft
Kill/EW)
Project (Number/Name)
0954 / Shipboard EW Improvement Program
B. Accomplishments/Planned Programs ($ in Millions, Article Quantities in Each)
FY 2019 FY 2020
FY 2021
Base
FY 2021
OCO
FY 2021
Total
Initiate development of methods for predicting and monitoring AN/SLQ-32(V)6 detection range performance
against emitters of interest for mission planning, daily operations planning, and real-time monitoring; Initiate
development of methods for predicting the passive fix accuracy based on specific or predicted conditions, for
multiple passive sensors including multiple AN/SLQ-32(V)6 equipped ships.
- Identify additional EW technology shortfalls and capability gaps based on the current and emerging Anti-
Ship Missile (ASM) threats and fleet requirements; Solicit industry, University Affiliate Research Centers or
government activities for technical solutions; Evaluate and select RCIP technology candidates; Evaluate RCIP
technologies production readiness; Develop execution plans for selected candidates based on evaluated
readiness and countermeasure technology prioritization.
FY 2021 Base Plans:
- Continue RCIP #4 SKCS efforts to address platform gaps for automatic and semi-automatic engagements
using Nulka decoys, onboard Electronic Attack (EA) (AN/SLQ-32 (V)7), and offboard EA systems; Initiate and
complete software development and system integration and testing activities for delivery of completed software
builds with capabilities including coordination of Nulka and combination engagements with AN/SLQ-32(V)6,
AN/SLQ-32(V)7, and offboard EW for enhanced coordination technique deployment; Continue integration and
testing activities in support of AEGIS ACB 20 (Baseline 10) by participating in AEGIS ACB 20 integration events
and preparing a fully tested software build for element certification; Complete SKCS FQT for a software build in
support of AN/SLQ-32(V)6 FQT, and continue to participate in system integration events with AN/ SLQ-32(V)6,
AN/SLQ-32(V)7 and Offboard EW; Continue SSDS ACB 20, OPC, and FFG(X) integration support efforts.
- Continue the transition of the Future Naval Capability (FNC) program, Softkill Performance and Real-Time
Assessment (SPARTA) into SKCS; Utilize developed algorithms to measure and improve key features observed
in Softkill (SK) engagements and EA effectiveness, and perform real-time assessment of SK performance;
Continue to develop and update the interface, architecture and algorithms required for full transition into SKCS,
taking into account ongoing SKCS build and capability completions; Initiate the transition of SPARTA into an
SKCS Build for AEGIS ACB 20.
- Complete SEWTT development of trainer enhancements including additional SKCS, Nulka, and Offboard EW
capabilities; Complete testing, integration, and documentation of the enhanced trainer and update associated
training materials.
- Complete the prototype and demonstration of AN/SLQ-32(V)6 and AN/SLQ-32(V)7 Electronic Support
(ES) system algorithm enhancements to provide advanced EW electronic sensing capabilities; Complete
development activities for a new EA technique capable of addressing a new identified anti-ship missile (ASM)
threat, including demonstration of the technique's effectiveness and readiness to be integrated into SEWIP.
Volume 3 - 1212
UNCLASSIFIED
PE 0604757N: Ship Self Def (Engage: Soft Kill/EW)
UNCLASSIFIED
Navy Page 7 of 37 R-1 Line #144
Exhibit R-2A, RDT&E Project Justification: PB2021Navy
Date: February 2020
Appropriation/Budget Activity
1319 / 5
R-1 Program Element (Number/Name)
PE 0604757N / Ship Self Def (Engage: Soft
Kill/EW)
Project (Number/Name)
0954 / Shipboard EW Improvement Program
B. Accomplishments/Planned Programs ($ in Millions, Article Quantities in Each)
FY 2019 FY 2020
FY 2021
Base
FY 2021
OCO
FY 2021
Total
- Continue development of methods to improve radio frequency (RF) sensor planning for the Propagation
Channel Assessment and Prediction (PCAP) FNC to add the capability to convey to EW and other shipboard
personnel how the current and expected RF propagation conditions are affecting the ship's passive RF sensors;
Conduct research to evaluate if the effects of both surface and evaporative ducting conditions on RF propagation
are currently accurately captured; Perform initial software development activities for an AN/SLQ-32(V)6 Signal
Nominal Range (SNR) Tool including coding of a Tactical Computer Software Configuration Item (CSCI) for the
SEWIP program to include the SNR tool functionality into the EW operator and EW supervisor tactical interfaces.
- Support the completion of final testing for CESARS component Multi-spectral EO/IR Countermeasures against
Advanced Threats (MEIRCAT); Complete the interface, architecture, and ship integration for CESARS transition
into the SEWIP program; Complete the SKCS pre-design material required to include CESARS capability.
- Initiate RCIP #6 AN/SLQ-32 (V)6 Built In Test (BIT) improvements which focus on increasing the AN/
SLQ-32(V)6 operator's tactical situational awareness and confidence in both system performance and the
ability to successfully carry out shipboard repairs; Evaluate the current state of BIT effectiveness and analyze
a candidate solution set to determine an optimal solution to be developed and released in two phases; Initiate
the implementation, test, and release of the identified solution by: performing architecture and software
code changes needed to support independent AN/SLQ-32(V)6 tactical and BIT development, testing on an
engineering system, validating BIT improvements, and preparing the Phase 1 software delivery for verification
and validation in a AN/SLQ-32(V)6 software test cycle and combat system (CS) testing.
- Identify additional EW technology shortfalls and capability gaps based on the current and emerging Anti-
Ship Missile (ASM) threats and fleet requirements; Solicit industry, University Affiliate Research Centers or
government activities for technical solutions; Evaluate and select RCIP technology candidates; Evaluate RCIP
technologies production readiness; Develop execution plans for selected candidates based on evaluated
readiness and countermeasure technology prioritization.
FY 2021 OCO Plans:
N/A
FY 2020 to FY 2021 Increase/Decrease Statement:
- Increase in FY2021 due to minor program and rate adjustments.
Accomplishments/Planned Programs Subtotals
10.913 15.865 16.375 0.000 16.375
Volume 3 - 1213
UNCLASSIFIED
PE 0604757N: Ship Self Def (Engage: Soft Kill/EW)
UNCLASSIFIED
Navy Page 8 of 37 R-1 Line #144
Exhibit R-2A, RDT&E Project Justification: PB2021Navy
Date: February 2020
Appropriation/Budget Activity
1319 / 5
R-1 Program Element (Number/Name)
PE 0604757N / Ship Self Def (Engage: Soft
Kill/EW)
Project (Number/Name)
0954 / Shipboard EW Improvement Program
C. Other Program Funding Summary ($ in Millions)
Line Item FY 2019 FY 2020
FY 2021
Base
FY 2021
OCO
FY 2021
Total FY 2022 FY 2023 FY 2024 FY 2025
Cost To
Complete Total Cost
• OPN/2312: OPN
BA-2 AN/SLQ-32(V)
352.677 340.706 387.195 - 387.195 417.015 404.848 345.809 349.898 2,339.826 6,195.165
• 24575N & 72827N/1C1C:
OMN BA-1 AN/SLQ-32(V)
7.102 6.122 4.524 - 4.524 4.719 4.883 5.033 5.145 Continuing Continuing
Remarks
D. Acquisition Strategy
The Rapid Capability Insertion Process (RCIP) is a process that identifies candidate capability gap/technology solution pairs, refines the value proposition description for
each pair, prioritizes projects for funding and executes projects that result in improved capability transitioned to the fleet.
Volume 3 - 1214
UNCLASSIFIED
PE 0604757N: Ship Self Def (Engage: Soft Kill/EW)
UNCLASSIFIED
Navy Page 9 of 37 R-1 Line #144
Exhibit R-3, RDT&E Project Cost Analysis: PB2021Navy
Date: February 2020
Appropriation/Budget Activity
1319 / 5
R-1 Program Element (Number/Name)
PE 0604757N / Ship Self Def (Engage: Soft
Kill/EW)
Project (Number/Name)
0954 / Shipboard EW Improvement Program
Product Development ($ in Millions)
FY 2019 FY 2020
FY 2021
Base
FY 2021
OCO
FY 2021
Total
Cost Category Item
Contract
Method
& Type
Performing
Activity & Location
Prior
Years Cost
Award
Date Cost
Award
Date Cost
Award
Date Cost
Award
Date Cost
Cost To
Complete
Total
Cost
Target
Value of
Contract
RCIP #4 SKCS SS/CPFF APL : Laurel, MD 4.268 1.367 Dec 2018 2.010 Nov 2019 2.939 Dec 2020 - 2.939 Continuing Continuing Continuing
RCIP #4 SKCS WR
NSWC Dahlgren :
Dahlgren, VA
7.454 2.441 Nov 2018 4.947 Nov 2019 5.542 Nov 2020 - 5.542 Continuing Continuing Continuing
RCIP #5 TACSIM WR
NSWC Dahlgren :
Dahlgren, VA
3.527 1.144 Dec 2018 1.700 Nov 2019 0.000 - 0.000 Continuing Continuing Continuing
SEWTT Development SS/CPFF EWA : Fairmont, WV 0.359 0.306 Feb 2019 0.560 Nov 2019 0.300 Nov 2020 - 0.300 Continuing Continuing Continuing
CESARS WR
NRL : Washington,
DC
0.000 0.937 Dec 2018 1.781 Nov 2019 0.647 Nov 2020 - 0.647 0.000 3.365 -
PCAP WR
NRL : Washington
DC
0.000 0.000 0.557 Nov 2019 1.046 Nov 2020 - 1.046 0.000 1.603 -
RCIP #6 BIT and
Processing Improvements
WR
NSWC Crane :
Crane, IN
0.000 0.000 0.000 Nov 2020 1.431 Nov 2020 - 1.431 0.000 1.431 -
AN/SLQ-32(V)6 and
(V)7 SW Algorithm
Enhancements
MIPR
MIT : Hanscom AFB,
MA
0.000 0.325 Jan 2019 0.301 Jan 2020 0.200 Jan 2021 - 0.200 0.000 0.826 -
Subtotal
15.608 6.520 11.856 12.105 - 12.105 Continuing Continuing N/A
Support ($ in Millions)
FY 2019 FY 2020
FY 2021
Base
FY 2021
OCO
FY 2021
Total
Cost Category Item
Contract
Method
& Type
Performing
Activity & Location
Prior
Years Cost
Award
Date Cost
Award
Date Cost
Award
Date Cost
Award
Date Cost
Cost To
Complete
Total
Cost
Target
Value of
Contract
Block 1 Government
Engineering Support
WR
NSWC Dahlgren :
Dahlgren, VA
6.990 0.607 Nov 2018 0.461 Nov 2019 0.440 Nov 2020 - 0.440 Continuing Continuing Continuing
Block 1 Government
Engineering Support
WR
NSWC Crane :
Crane, IN
5.295 0.533 Dec 2018 0.521 Nov 2019 0.502 Nov 2020 - 0.502 Continuing Continuing Continuing
Block 1 Government
Engineering Support
WR
NRL : Washington,
DC
3.962 0.344 Dec 2018 0.223 Nov 2019 0.000 - 0.000 0.000 4.529 Continuing
Block 1 Government
Engineering Support
SS/CPFF APL : Laurel, MD 2.865 0.635 Dec 2018 0.282 Nov 2019 0.495 Nov 2020 - 0.495 Continuing Continuing Continuing
Block 1 Government
Engineering Support
MIPR
MIT : Hanscom AFB,
MA
1.070 0.762 Dec 2018 0.802 Nov 2019 0.792 Nov 2020 - 0.792 Continuing Continuing Continuing
Volume 3 - 1215
UNCLASSIFIED
PE 0604757N: Ship Self Def (Engage: Soft Kill/EW)
UNCLASSIFIED
Navy Page 10 of 37 R-1 Line #144
Exhibit R-3, RDT&E Project Cost Analysis: PB2021Navy
Date: February 2020
Appropriation/Budget Activity
1319 / 5
R-1 Program Element (Number/Name)
PE 0604757N / Ship Self Def (Engage: Soft
Kill/EW)
Project (Number/Name)
0954 / Shipboard EW Improvement Program
Support ($ in Millions)
FY 2019 FY 2020
FY 2021
Base
FY 2021
OCO
FY 2021
Total
Cost Category Item
Contract
Method
& Type
Performing
Activity & Location
Prior
Years Cost
Award
Date Cost
Award
Date Cost
Award
Date Cost
Award
Date Cost
Cost To
Complete
Total
Cost
Target
Value of
Contract
Block 1 Government
Engineering Support
MIPR
DISA : Fort Meade,
MD
0.050 0.000 0.000 0.000 - 0.000 0.000 0.050 -
Subtotal
20.232 2.881 2.289 2.229 - 2.229 Continuing Continuing N/A
Test and Evaluation ($ in Millions)
FY 2019 FY 2020
FY 2021
Base
FY 2021
OCO
FY 2021
Total
Cost Category Item
Contract
Method
& Type
Performing
Activity & Location
Prior
Years Cost
Award
Date Cost
Award
Date Cost
Award
Date Cost
Award
Date Cost
Cost To
Complete
Total
Cost
Target
Value of
Contract
RCIP Test Planning/T&E
Events
WR
NSWC Dahlgren :
Dahlgren, VA
2.216 0.529 Nov 2018 0.448 Nov 2019 0.797 Nov 2020 - 0.797 Continuing Continuing Continuing
RCIP Test Planning/T&E
Events
WR
NSWC Crane :
Crane, IN
0.889 0.000 0.000 0.000 - 0.000 0.000 0.889 -
RCIP Test Planning/T&E
Events
WR
NRL : Washington,
DC
1.729 0.317 Dec 2018 0.446 Nov 2019 0.604 Nov 2020 - 0.604 Continuing Continuing Continuing
RCIP Test Planning/T&E
Events
SS/CPFF APL : Laurel, MD 0.100 0.000 0.000 0.000 - 0.000 0.000 0.100 -
RCIP Test Planning/T&E
Events
WR
COMOPTEVFOR :
Norfolk, VA
0.104 0.000 0.000 0.000 - 0.000 0.000 0.104 -
Subtotal
5.038 0.846 0.894 1.401 - 1.401 Continuing Continuing N/A
Management Services ($ in Millions)
FY 2019 FY 2020
FY 2021
Base
FY 2021
OCO
FY 2021
Total
Cost Category Item
Contract
Method
& Type
Performing
Activity & Location
Prior
Years Cost
Award
Date Cost
Award
Date Cost
Award
Date Cost
Award
Date Cost
Cost To
Complete
Total
Cost
Target
Value of
Contract
Block 1 Program
Management Support
C/CPIF
TMB (SEAPORT) :
Washington, D.C.
0.794 0.221 Jan 2019 0.262 Nov 2019 0.200 Nov 2020 - 0.200 Continuing Continuing Continuing
Block 1 Program
Management Support
C/CPIF
SPA : Washington,
DC
0.743 0.221 Dec 2018 0.262 Nov 2019 0.200 Nov 2020 - 0.200 Continuing Continuing Continuing
Block 1 Program
Managment Support
C/CPIF
CACI (SEAPORT) :
Washington, DC
0.229 0.221 Jan 2019 0.262 Nov 2019 0.200 Nov 2020 - 0.200 0.000 0.912 -
Volume 3 - 1216
UNCLASSIFIED
PE 0604757N: Ship Self Def (Engage: Soft Kill/EW)
UNCLASSIFIED
Navy Page 11 of 37 R-1 Line #144
Exhibit R-3, RDT&E Project Cost Analysis: PB2021Navy
Date: February 2020
Appropriation/Budget Activity
1319 / 5
R-1 Program Element (Number/Name)
PE 0604757N / Ship Self Def (Engage: Soft
Kill/EW)
Project (Number/Name)
0954 / Shipboard EW Improvement Program
Management Services ($ in Millions)
FY 2019 FY 2020
FY 2021
Base
FY 2021
OCO
FY 2021
Total
Cost Category Item
Contract
Method
& Type
Performing
Activity & Location
Prior
Years Cost
Award
Date Cost
Award
Date Cost
Award
Date Cost
Award
Date Cost
Cost To
Complete
Total
Cost
Target
Value of
Contract
Block 1 Travel Sub Allot
NAVSEA Program
Office Travel :
Washington, DC
1.363 0.003 Dec 2018 0.040 Nov 2019 0.040 Nov 2020 - 0.040 Continuing Continuing Continuing
Subtotal
3.129 0.666 0.826 0.640 - 0.640 Continuing Continuing N/A
Prior
Years FY 2019 FY 2020
FY 2021
Base
FY 2021
OCO
FY 2021
Total
Cost To
Complete
Total
Cost
Target
Value of
Contract
Project Cost Totals
44.007 10.913 15.865 16.375 - 16.375 Continuing Continuing N/A
Remarks
Since FY 2020 President's Budget request, FY19 funds were realigned to higher Navy priorities for SEWIP Block 3.
Volume 3 - 1217
UNCLASSIFIED
PE 0604757N: Ship Self Def (Engage: Soft Kill/EW)
UNCLASSIFIED
Navy Page 12 of 37 R-1 Line #144
Exhibit R-4, RDT&E Schedule Profile: PB2021Navy
Date: February 2020
Appropriation/Budget Activity
1319 / 5
R-1 Program Element (Number/Name)
PE 0604757N / Ship Self Def (Engage: Soft
Kill/EW)
Project (Number/Name)
0954 / Shipboard EW Improvement Program
Volume 3 - 1218
UNCLASSIFIED
PE 0604757N: Ship Self Def (Engage: Soft Kill/EW)
UNCLASSIFIED
Navy Page 13 of 37 R-1 Line #144
Exhibit R-4A, RDT&E Schedule Details: PB2021Navy
Date: February 2020
Appropriation/Budget Activity
1319 / 5
R-1 Program Element (Number/Name)
PE 0604757N / Ship Self Def (Engage: Soft
Kill/EW)
Project (Number/Name)
0954 / Shipboard EW Improvement Program
Schedule Details
Start End
Events by Sub Project Quarter Year Quarter Year
Proj 0954
EW Rapid Capability Insertion Process (RCIP) 1 2019 4 2025
RCIP #4: SKCS 1 2019 4 2025
Softkill Performance and Real-Time Assessment (SPARTA) 1 2019 2 2022
RCIP #5 TACSIM 1 2019 4 2020
RCIP #6: BIT and Processing Improvements 2 2021 4 2023
AN/SLQ-32(V)6 and AN/SLQ-32(V)7 Software Algorithm Enhancements 2 2019 4 2023
Combined EO/IR Surveillance and Response System (CESARS) 1 2019 2 2021
Propagation Channel Assessment and Prediction 1 2020 4 2023
RCIP #4 SKCS SW Build Delivery 4 2019 4 2025
RCIP #5 TACSIM SW Integration and Delivery 4 2019 4 2020
RCIP #6 BIT and Processing Improvements SW Delivery 1 2022 3 2023
Volume 3 - 1219
UNCLASSIFIED
PE 0604757N: Ship Self Def (Engage: Soft Kill/EW)
UNCLASSIFIED
Navy Page 14 of 37 R-1 Line #144
Exhibit R-2A, RDT&E Project Justification: PB2021Navy
Date: February 2020
Appropriation/Budget Activity
1319 / 5
R-1 Program Element (Number/Name)
PE 0604757N / Ship Self Def (Engage: Soft
Kill/EW)
Project (Number/Name)
2190 / NULKA Decoy
COST ($ in Millions)
Prior
Years FY 2019 FY 2020
FY 2021
Base
FY 2021
OCO
FY 2021
Total FY 2022 FY 2023 FY 2024 FY 2025
Cost To
Complete
Total
Cost
2190: NULKA Decoy
43.427 3.805 5.090 5.291 - 5.291 6.962 7.036 7.179 7.322 Continuing Continuing
Quantity of RDT&E Articles - - - - - - - - -
A. Mission Description and Budget Item Justification
The Offboard Active Decoy (NULKA) is a joint cooperative program between the United States and Australia that developed an active offboard decoy that utilizes a
broadband radio frequency repeater mounted atop a hovering rocket. NULKA counters a wide variety of present and future radar guided Anti-Ship Missiles (ASMs)
by radiating a large radar cross section while flying a ship-like trajectory. The United States developed the electronic payload and fire control system, while Australia
developed the hovering rocket. FY21 funding includes Decoy Launcher Processor (DLP) technology refresh to address obsolescence issues. This effort consists of
development of the Decoy Launch Message Convertor (DLMC) and delivery of Engineering Development Models (EDMs) to support Factory Qualification Testing (FQT)
and Environmental Qualification Testing (EQT) to improve employment of the NULKA system.
B. Accomplishments/Planned Programs ($ in Millions, Article Quantities in Each)
FY 2019 FY 2020
FY 2021
Base
FY 2021
OCO
FY 2021
Total
Title: NULKA Decoy Subsystem
Articles:
FY 2020 Plans:
- Conduct engineering and effectiveness studies to evaluate new and existing threats; update Fly-Out Tactics
table for specific platforms (as appropriate)
- Develop NULKA-X/Y modeling and simulation tools and update lab equipment to support threat assessments
- Continue Decoy Launch Processor (DLP) technology refresh to design and develop hardware obsolescence
solutions
- Deliver DLPP 6_8 software that will integrate with NULKA-X/Y
- Commence development of DLPP 6_9 software that will integrate with SKCS and Advanced NULKA Decoy
- Continue development of the Decoy Launch Message Convertor (DLMC)
- Deliver DLMC Engineering Development Models (EDMs) to support Factory Qualification Testing (FQT) and
Environmental Qualification Testing (EQT) to improve employment of the NULKA system
- Commence planning for FQT/EQT
FY 2021 Base Plans:
- Continue engineering and effectiveness studies to evaluate new and existing threats; update Fly-Out Tactics
table for specific platforms (as appropriate)
- Continue Decoy Launch Processor (DLP) technology refresh to design and develop hardware obsolescence
solutions
3.805
-
5.090
-
5.291
-
0.000
-
5.291
-
Volume 3 - 1220
UNCLASSIFIED
PE 0604757N: Ship Self Def (Engage: Soft Kill/EW)
UNCLASSIFIED
Navy Page 15 of 37 R-1 Line #144
Exhibit R-2A, RDT&E Project Justification: PB2021Navy
Date: February 2020
Appropriation/Budget Activity
1319 / 5
R-1 Program Element (Number/Name)
PE 0604757N / Ship Self Def (Engage: Soft
Kill/EW)
Project (Number/Name)
2190 / NULKA Decoy
B. Accomplishments/Planned Programs ($ in Millions, Article Quantities in Each)
FY 2019 FY 2020
FY 2021
Base
FY 2021
OCO
FY 2021
Total
- Continue development and deliver DLPP 6_9 software that will integrate with SKCS and Advanced NULKA
Decoy
- Continue development of the Decoy Launch Message Convertor (DLMC)
- Conduct DLMC FQT/EQT
FY 2021 OCO Plans:
N/A
FY 2020 to FY 2021 Increase/Decrease Statement:
Increase in FY21 supports Factory Qualification Testing (FQT) and Environmental Qualification Testing (EQT).
Accomplishments/Planned Programs Subtotals
3.805 5.090 5.291 0.000 5.291
C. Other Program Funding Summary ($ in Millions)
Line Item FY 2019 FY 2020
FY 2021
Base
FY 2021
OCO
FY 2021
Total FY 2022 FY 2023 FY 2024 FY 2025
Cost To
Complete Total Cost
• OPN/5231: Ship Missile
Support Equipment
30.278 0.000 0.000 - 0.000 0.000 0.000 0.000 0.000 Continuing Continuing
• OPN/5530: Anti-Ship
Missile Decoy System
0.000 38.462 86.356 - 86.356 79.795 71.385 72.662 74.098 385.957 808.715
• OMN/11CD0 (1C1C): NULKA 5.776 6.155 7.058 - 7.058 7.828 8.012 8.220 8.149 Continuing Continuing
Remarks
In FY20, NULKA OPN funds were realigned from BLI 5231 to BLI 5530.
D. Acquisition Strategy
NULKA is a joint cooperative program between United States and Australia.
Volume 3 - 1221
UNCLASSIFIED
PE 0604757N: Ship Self Def (Engage: Soft Kill/EW)
UNCLASSIFIED
Navy Page 16 of 37 R-1 Line #144
Exhibit R-3, RDT&E Project Cost Analysis: PB2021Navy
Date: February 2020
Appropriation/Budget Activity
1319 / 5
R-1 Program Element (Number/Name)
PE 0604757N / Ship Self Def (Engage: Soft
Kill/EW)
Project (Number/Name)
2190 / NULKA Decoy
Product Development ($ in Millions)
FY 2019 FY 2020
FY 2021
Base
FY 2021
OCO
FY 2021
Total
Cost Category Item
Contract
Method
& Type
Performing
Activity & Location
Prior
Years Cost
Award
Date Cost
Award
Date Cost
Award
Date Cost
Award
Date Cost
Cost To
Complete
Total
Cost
Target
Value of
Contract
Systems Engineering WR
NRL : Washington,
DC
20.577 0.700 Dec 2018 1.689 Nov 2019 0.951 Nov 2020 - 0.951 Continuing Continuing Continuing
Systems Engineering WR
NSWC Dahlgren :
Dahlgren, VA
13.525 2.376 Dec 2018 1.678 Jan 2020 1.954 Nov 2020 - 1.954 Continuing Continuing Continuing
Systems Engineering WR NSWC Crane : IN 7.663 0.204 Dec 2018 1.275 Nov 2019 1.985 Nov 2020 - 1.985 Continuing Continuing Continuing
Subtotal
41.765 3.280 4.642 4.890 - 4.890 Continuing Continuing N/A
Remarks
FY20 NRL increase is due to NULKA-X/Y modeling and simulation development as well as non-recurring hardware costs to update lab equipment to support threat
assessments. FY20 Crane increase is due to DLMC development.
Management Services ($ in Millions)
FY 2019 FY 2020
FY 2021
Base
FY 2021
OCO
FY 2021
Total
Cost Category Item
Contract
Method
& Type
Performing
Activity & Location
Prior
Years Cost
Award
Date Cost
Award
Date Cost
Award
Date Cost
Award
Date Cost
Cost To
Complete
Total
Cost
Target
Value of
Contract
Program Management
Support
C/CPIF
ICI (SEAPORT) :
Washington, DC
0.221 0.102 Jan 2019 0.000 0.000 - 0.000 0.000 0.323 -
Program Management
Support
C/CPIF
TMB (SEAPORT) :
Washington, DC
0.363 0.102 Jan 2019 0.106 Feb 2020 0.107 Nov 2020 - 0.107 Continuing Continuing Continuing
Program Management
Support
C/CPIF
SPA : Washington,
DC
0.395 0.306 Dec 2018 0.332 Feb 2020 0.284 Nov 2020 - 0.284 Continuing Continuing Continuing
Travel Allot
NAVSEA Program
Office Travel :
Washington, DC
0.683 0.015 Nov 2018 0.010 Nov 2019 0.010 Nov 2020 - 0.010 Continuing Continuing Continuing
Subtotal
1.662 0.525 0.448 0.401 - 0.401 Continuing Continuing N/A
Prior
Years FY 2019 FY 2020
FY 2021
Base
FY 2021
OCO
FY 2021
Total
Cost To
Complete
Total
Cost
Target
Value of
Contract
Project Cost Totals
43.427 3.805 5.090 5.291 - 5.291 Continuing Continuing N/A
Remarks
Volume 3 - 1222
UNCLASSIFIED
PE 0604757N: Ship Self Def (Engage: Soft Kill/EW)
UNCLASSIFIED
Navy Page 17 of 37 R-1 Line #144
Exhibit R-4, RDT&E Schedule Profile: PB2021Navy
Date: February 2020
Appropriation/Budget Activity
1319 / 5
R-1 Program Element (Number/Name)
PE 0604757N / Ship Self Def (Engage: Soft
Kill/EW)
Project (Number/Name)
2190 / NULKA Decoy
Volume 3 - 1223
UNCLASSIFIED
PE 0604757N: Ship Self Def (Engage: Soft Kill/EW)
UNCLASSIFIED
Navy Page 18 of 37 R-1 Line #144
Exhibit R-4A, RDT&E Schedule Details: PB2021Navy
Date: February 2020
Appropriation/Budget Activity
1319 / 5
R-1 Program Element (Number/Name)
PE 0604757N / Ship Self Def (Engage: Soft
Kill/EW)
Project (Number/Name)
2190 / NULKA Decoy
Schedule Details
Start End
Events by Sub Project Quarter Year Quarter Year
Proj 2190
Threat Assessment Updates 1 2019 4 2025
Decoy Launch Processor (DLP) Tech Refresh 1 2019 4 2025
DLPP 6_8 1 2019 2 2020
DLPP 6_9 3 2020 4 2021
Decoy Launch Message Convertor (DLMC) Development 4 2019 4 2022
DLMC Engineering Development Model (EDM) Units 4 2020 4 2020
DLMC Facotry Qualification Testing (FQT) 1 2021 3 2021
DLMC Environmental Qualification Testing (EQT) 1 2021 4 2021
Nulka Objective Architecture 1 2022 2 2025
Volume 3 - 1224
UNCLASSIFIED
PE 0604757N: Ship Self Def (Engage: Soft Kill/EW)
UNCLASSIFIED
Navy Page 19 of 37 R-1 Line #144
Exhibit R-2A, RDT&E Project Justification: PB2021Navy
Date: February 2020
Appropriation/Budget Activity
1319 / 5
R-1 Program Element (Number/Name)
PE 0604757N / Ship Self Def (Engage: Soft
Kill/EW)
Project (Number/Name)
3316 / Advanced Offboard EW
COST ($ in Millions)
Prior
Years FY 2019 FY 2020
FY 2021
Base
FY 2021
OCO
FY 2021
Total FY 2022 FY 2023 FY 2024 FY 2025
Cost To
Complete
Total
Cost
3316: Advanced Offboard EW
160.758 70.691 52.198 44.814 - 44.814 10.203 10.283 4.960 5.060 Continuing Continuing
Quantity of RDT&E Articles - - - - - - - - -
A. Mission Description and Budget Item Justification
3316 - The Advanced Offboard EW (AOEW) program is for the development of long duration off-board decoys integrated with onboard systems for EW coordination to
counter identified EW gaps (additional details classified) in response to an urgent operational need from the Fleet that has been approved by the CNO for execution.
Currently no counter to the threat exists. In FY12, the program began with a Rapid Response Effort (RRE) which was completed in FY 2014. The RRE consisted of
the evaluation and integration of commercially available decoys. The Decoy Development Effort (DDE) consists of the development and evaluation of a long duration,
active electronic offboard decoy system (payload) integrated on an existing flight vehicle (MH-60R/MH-60S), integration with ship and air systems, and a government
software development effort to integrate AOEW into the Soft Kill Coordination System (SKCS) to gain maximum effectiveness from the decoy through coordination with
an onboard system.
The DDE Preliminary Design contract was awarded Dec 2016 followed by a System Requirements Review (SRR)/System Functional Review (SFR) leading to a
Preliminary Development Review (PDR) in Sep 2017. The Engineering Manufacturing and Development (EMD) Option was awarded in Sep 2017. The program
schedule was revised to align with funding limitations in FY17 through FY20, however in FY21 the budget increases to support completion of critical technical tasking.
The Factory Qualification Test (FQT) will be completed on the Engineering Development Models (EDMs) to support completion and delivery of the Technical Data
Package (TDP) and developmental testing. As a result, developmental testing is scheduled to complete in FY22 and operational testing is scheduled to complete in
FY23. Operational test results (Initial Operational Test & Evaluation) is planned to support the Full Rate Production (FRP) decision scheduled for FY23.
NAVAIR Avionics Operating Program (AOP) software development and Flight Certification are required to support fielding of the AOEW decoy. The AOP software
supports integration of the AOEW decoy with the MH-60R/S airframe and is required for successful completion of Flight Certification. Flight Certification ensures
operational Safety of Flight and is critical to successful decoy fielding. NAVAIR Flight Certification will complete in FY22.
B. Accomplishments/Planned Programs ($ in Millions, Article Quantities in Each)
FY 2019 FY 2020
FY 2021
Base
FY 2021
OCO
FY 2021
Total
Title: AOEW - Decoy Development Effort (DDE) Government Engineering
Articles:
FY 2020 Plans:
- Complete MS-C planning and documentation preparation
- Conduct Integrated Logistics Assessment (ILA)
- Conduct MS-C
- Continue interoperability analysis to ensure all system of systems are compatible
20.710
-
19.898
-
23.645
-
0.000
-
23.645
-
Volume 3 - 1225
UNCLASSIFIED
PE 0604757N: Ship Self Def (Engage: Soft Kill/EW)
UNCLASSIFIED
Navy Page 20 of 37 R-1 Line #144
Exhibit R-2A, RDT&E Project Justification: PB2021Navy
Date: February 2020
Appropriation/Budget Activity
1319 / 5
R-1 Program Element (Number/Name)
PE 0604757N / Ship Self Def (Engage: Soft
Kill/EW)
Project (Number/Name)
3316 / Advanced Offboard EW
B. Accomplishments/Planned Programs ($ in Millions, Article Quantities in Each)
FY 2019 FY 2020
FY 2021
Base
FY 2021
OCO
FY 2021
Total
- Continue tactics analysis and development
- Continue integration of ship and air interfaces
- Continue SKCS development specific to AOEW
- Continue development and testing of Avionics Operating Program (AOP) to update MH-60R/S software
necessary for AOEW decoy and Helicopter Integration
- Commence support of Trouble Report (TR) resolution for AOP software deliveries
- Continue integration planning and testing of AOEW MH-60R/S, Combat Management System (CMS), SKCS,
Command and Control Processor (C2P), and AOP
- Continue sustainment and training plan development
- Commence identification of and update of test assets needed to support Operational Testing
- Continue test and Modeling & Simulation (M&S) development for Electronic Warfare Test Bed (EWTB)
- Continue Surface Electronic Warfare Team Trainer (SEWTT) functionality development for the AOEW Decoy
- Commence support of Factory Qualification Test (FQT)
- Continue support of Test and Certification
- Conduct Developmental Test (DT) Assist
- Commence technique verification
- Commence configuration management of Engineering Development Model (EDM) assets and baselines in
support of programmatic needs
- Continue Engineering Data Requirements Agreement Plan (EDRAP) Development
- Continue NAVAIR MH-60R/S flight certification testing of EDMs. Flight certification is required by NAVAIR to
ensure Safety of Flight and to certify the interoperability between the MH-60R/S and the AOEW decoy. Flight
certification tests include: Ground and Flight Jettison, Flight Test for Mission Performance / Spec Compliance
Flight Test, Functional Software Test, and Decoy Fit and Egress Test
- Complete updates to the Capability Development Document (CDD)
- Continue installation planning
- Commence support of Security Software development
- Commence support of Environmental/Electro Magnetic Interference (EMI) test planning
- Commence and complete battery planning and certification
FY 2021 Base Plans:
- Continue interoperability analysis to ensure all system of systems are compatible
- Continue tactics analysis and development
- Continue integration of ship and air interfaces
Volume 3 - 1226
UNCLASSIFIED
PE 0604757N: Ship Self Def (Engage: Soft Kill/EW)
UNCLASSIFIED
Navy Page 21 of 37 R-1 Line #144
Exhibit R-2A, RDT&E Project Justification: PB2021Navy
Date: February 2020
Appropriation/Budget Activity
1319 / 5
R-1 Program Element (Number/Name)
PE 0604757N / Ship Self Def (Engage: Soft
Kill/EW)
Project (Number/Name)
3316 / Advanced Offboard EW
B. Accomplishments/Planned Programs ($ in Millions, Article Quantities in Each)
FY 2019 FY 2020
FY 2021
Base
FY 2021
OCO
FY 2021
Total
- Continue SKCS development specific to AOEW
- Continue development and testing of AOP to update MH-60R/S software necessary for AOEW decoy and
Helicopter Integration
- Continue support of Trouble Report (TR) resolution for AOP software deliveries
- Continue integration planning and testing of AOEW MH-60R/S, CMS, SKCS, C2P, and AOP
- Continue sustainment and training plan development
- Continue identification of and update of test assets needed to support Operational Testing
- Continue test and M&S development for EWTB
- Continue SEWTT functionality development for the AOEW Decoy
- Continue support of FQT
- Continue support of Test and Certification
- Continue technique verification
- Continue configuration management of EDM assets and baselines in support of programmatic needs
- Continue EDRAP Development
- Continue NAVAIR MH-60R/S flight certification testing of EDMs. Flight certification is required by NAVAIR to
ensure Safety of Flight and to certify the interoperability between the MH-60R/S and the AOEW decoy. Flight
certification tests include: Ground and Flight Jettison, Flight Test for Mission Performance / Spec Compliance
Flight Test, Functional Software Test, and Decoy Fit and Egress Test
- Commence Production Readiness Review (PRR)
- Continue installation planning
- Continue support of Security Software development
- Commence support of Low Rate Initial Production (LRIP)
- Continue support of Environmental/EMI test planning
FY 2021 OCO Plans:
N/A
FY 2020 to FY 2021 Increase/Decrease Statement:
Increase of Government Engineering in FY21 is due to a re-start of effort following a partial slow down of effort in
FY20, to remain within funding limitations.
Title: AOEW - Decoy Development Effort (DDE) Development
Articles:
FY 2020 Plans:
49.981
-
32.300
-
21.169
-
0.000
-
21.169
-
Volume 3 - 1227
UNCLASSIFIED
PE 0604757N: Ship Self Def (Engage: Soft Kill/EW)
UNCLASSIFIED
Navy Page 22 of 37 R-1 Line #144
Exhibit R-2A, RDT&E Project Justification: PB2021Navy
Date: February 2020
Appropriation/Budget Activity
1319 / 5
R-1 Program Element (Number/Name)
PE 0604757N / Ship Self Def (Engage: Soft
Kill/EW)
Project (Number/Name)
3316 / Advanced Offboard EW
B. Accomplishments/Planned Programs ($ in Millions, Article Quantities in Each)
FY 2019 FY 2020
FY 2021
Base
FY 2021
OCO
FY 2021
Total
- Continue Engineering Development Model (EDM) Hardware and Software development and integration
- Complete support of MS C planning and documentation preparation
- Complete support of ILA
- Complete support of MS C
- Continue to support AOP to update MH-60R and MH-60S software necessary for AOEW decoy and Helicopter
integration
- Continue to support integration planning and testing of AOEW, MH-60R/S, CMS, SKCS, C2P, and AOP
- Commence Factory Qualification Test (FQT) on an EDM
- Continue to support NAVAIR flight certification testing of EDMs. Flight certification is required by NAVAIR to
ensure Safety of Flight and to certify the interoperability between the MH-60R/S and AOEW decoy
- Support Developmental Test (DT) Assist
- Commence development of Security Software
- Commence Environmental/EMI Test planning
- Commence and complete support of battery planning and certification
- Continue development of Technical Data Package (TDP)
- Commence assembly of 4 EDMs
FY 2021 Base Plans:
- Continue EDM Hardware and Software development and integration
- Continue assembly of 3 EDMs
- Deliver 1 EDM
- Continue to support AOP to update MH-60R and MH-60S software necessary for AOEW decoy and Helicopter
integration
- Continue to support integration planning and testing of AOEW, MH-60R/S, CMS, SKCS, C2P, and AOP
- Continue FQT on an EDM
- Continue to support NAVAIR flight certification testing of EDMs. Flight certification is required by NAVAIR to
ensure Safety of Flight and to certify the interoperability between the MH-60R/S and AOEW decoy
- Commence support of Production Readiness Review (PRR)
- Continue Environmental/EMI Test planning
- Complete development and deliver final TDP
- Continue development of Security Software
- Procure LRIP material
Volume 3 - 1228
UNCLASSIFIED
PE 0604757N: Ship Self Def (Engage: Soft Kill/EW)
UNCLASSIFIED
Navy Page 23 of 37 R-1 Line #144
Exhibit R-2A, RDT&E Project Justification: PB2021Navy
Date: February 2020
Appropriation/Budget Activity
1319 / 5
R-1 Program Element (Number/Name)
PE 0604757N / Ship Self Def (Engage: Soft
Kill/EW)
Project (Number/Name)
3316 / Advanced Offboard EW
B. Accomplishments/Planned Programs ($ in Millions, Article Quantities in Each)
FY 2019 FY 2020
FY 2021
Base
FY 2021
OCO
FY 2021
Total
- Commence Assembly of LRIP units
FY 2021 OCO Plans:
N/A
FY 2020 to FY 2021 Increase/Decrease Statement:
Decrease of Development Engineering in FY21 is due to the completion of software development and antenna
array development and testing.
Accomplishments/Planned Programs Subtotals
70.691 52.198 44.814 0.000 44.814
C. Other Program Funding Summary ($ in Millions)
Line Item FY 2019 FY 2020
FY 2021
Base
FY 2021
OCO
FY 2021
Total FY 2022 FY 2023 FY 2024 FY 2025
Cost To
Complete Total Cost
• OPN/5530: Anti-ship
Missile Decoy System
0.000 0.000 32.671 - 32.671 18.906 0.000 0.000 0.000 0.000 51.577
Remarks
OPN Controls reflect the following Line Item 5530 Project Unit (PU) under the 'ANTI-SHIP MISSILE DECOY SYSTEM' program: VV500.
D. Acquisition Strategy
The AOEW DDE decoy is being competitively contracted and developed, and builds on technologies and concepts currently in development by ONR.
Volume 3 - 1229
UNCLASSIFIED
PE 0604757N: Ship Self Def (Engage: Soft Kill/EW)
UNCLASSIFIED
Navy Page 24 of 37 R-1 Line #144
Exhibit R-3, RDT&E Project Cost Analysis: PB2021Navy
Date: February 2020
Appropriation/Budget Activity
1319 / 5
R-1 Program Element (Number/Name)
PE 0604757N / Ship Self Def (Engage: Soft
Kill/EW)
Project (Number/Name)
3316 / Advanced Offboard EW
Product Development ($ in Millions)
FY 2019 FY 2020
FY 2021
Base
FY 2021
OCO
FY 2021
Total
Cost Category Item
Contract
Method
& Type
Performing
Activity & Location
Prior
Years Cost
Award
Date Cost
Award
Date Cost
Award
Date Cost
Award
Date Cost
Cost To
Complete
Total
Cost
Target
Value of
Contract
Concept Analysis and
Integration Assessment
SS/CPFF APL : Laurel, MD 11.707 0.000 0.000 0.000 - 0.000 0.000 11.707 Continuing
Concept Analysis and
Technology Studies
WR MIT-LL : Boston, MA 4.857 0.000 0.000 0.000 - 0.000 0.000 4.857 Continuing
Concept Development and
Technology Studies
WR
NRL : Washington,
D.C.
25.856 0.000 0.000 0.000 - 0.000 0.000 25.856 Continuing
Technology Development
and Systems
Requirements
WR
NSWC Dahlgren :
Dahlgren, VA
14.595 0.000 0.000 0.000 - 0.000 0.000 14.595 Continuing
DDE Avionics
Development
WR
NAVAIR : Patuxent
River, MD
5.189 6.475 Dec 2018 6.725 Nov 2019 1.456 Nov 2020 - 1.456 Continuing Continuing Continuing
DDE Preliminary Design/
E&MD
C/CPIF
Lockheed Martin :
Syracuse, NY
32.455 49.982 Oct 2018 32.300 Nov 2019 21.169 Nov 2020 - 21.169 Continuing Continuing Continuing
Ship Integration WR
SPAWAR : San
Diego, CA
0.975 0.000 0.000 0.000 - 0.000 0.000 0.975 -
Ship Integration WR
NSWC Dahlgren :
Dahlgren, VA
0.000 0.330 Dec 2018 0.000 0.000 - 0.000 0.000 0.330 -
Subtotal
95.634 56.787 39.025 22.625 - 22.625 Continuing Continuing N/A
Remarks
Since FY 2020 President's Budget request, increase in Product Development funding in FY20 is required to support critical Lockheed Martin Milestone C Planning efforts and
Engineering Development Model (EDM) assembly, integration and test. These efforts will continue in FY21.
Support ($ in Millions)
FY 2019 FY 2020
FY 2021
Base
FY 2021
OCO
FY 2021
Total
Cost Category Item
Contract
Method
& Type
Performing
Activity & Location
Prior
Years Cost
Award
Date Cost
Award
Date Cost
Award
Date Cost
Award
Date Cost
Cost To
Complete
Total
Cost
Target
Value of
Contract
Government Development
Support
WR
NRL : Washington,
DC
13.153 3.753 Jan 2019 2.977 Nov 2019 2.383 Nov 2020 - 2.383 Continuing Continuing Continuing
Government Development
and Engineering Support
WR
NSWC Dahlgren :
Dahlgren, VA
11.519 1.815 Dec 2018 1.240 Dec 2019 2.164 Nov 2020 - 2.164 Continuing Continuing Continuing
Volume 3 - 1230
UNCLASSIFIED
PE 0604757N: Ship Self Def (Engage: Soft Kill/EW)
UNCLASSIFIED
Navy Page 25 of 37 R-1 Line #144
Exhibit R-3, RDT&E Project Cost Analysis: PB2021Navy
Date: February 2020
Appropriation/Budget Activity
1319 / 5
R-1 Program Element (Number/Name)
PE 0604757N / Ship Self Def (Engage: Soft
Kill/EW)
Project (Number/Name)
3316 / Advanced Offboard EW
Support ($ in Millions)
FY 2019 FY 2020
FY 2021
Base
FY 2021
OCO
FY 2021
Total
Cost Category Item
Contract
Method
& Type
Performing
Activity & Location
Prior
Years Cost
Award
Date Cost
Award
Date Cost
Award
Date Cost
Award
Date Cost
Cost To
Complete
Total
Cost
Target
Value of
Contract
Government Engineering
Support
WR
NSWC Crane :
Crane, IN
13.353 2.491 Nov 2018 2.622 Nov 2019 3.554 Nov 2020 - 3.554 Continuing Continuing Continuing
Logistics/Training SS/CPFF EWA : Fairmont, WV 0.866 0.750 Feb 2019 0.100 Nov 2019 0.800 Nov 2020 - 0.800 Continuing Continuing Continuing
Government Engineering
Support
WR
NSWC Carderock :
Bethesda, MD
0.768 0.440 Feb 2019 0.050 Jan 2020 0.000 - 0.000 0.000 1.258 -
Systems Engineering
Support
SS/CPFF APL : Laurel, MD 5.822 1.564 Jan 2019 0.395 Jan 2020 0.395 Nov 2020 - 0.395 Continuing Continuing Continuing
Government Development
Support
WR
NAVAIR : Patuxent
River, MD
4.670 0.933 Dec 2018 1.536 Nov 2019 1.500 Nov 2020 - 1.500 Continuing Continuing Continuing
Systems Engineering
Support
WR MIT-LL : Boston, MA 0.034 0.000 0.000 0.000 - 0.000 0.000 0.034 -
Program Management
Support
WR
DISA : Pensacola,
FL
0.195 0.000 0.000 0.000 - 0.000 0.000 0.195 -
Installation Support WR Supship : Bath, ME 0.005 0.093 Feb 2019 0.025 Jan 2020 0.150 Nov 2020 - 0.150 Continuing Continuing Continuing
Integrated Logistics
Assessment
WR Corona : Norco, CA 0.000 0.000 0.000 0.000 - 0.000 0.000 0.000 -
Engineering Services C/BA
Lockheed Martin :
Syracuse, NY
0.000 0.000 0.000 0.100 Nov 2020 - 0.100 0.000 0.100 -
Battery Design WR
NSWC Philadelphia :
Philadelphia, PA
0.000 0.000 0.000 0.800 Nov 2020 - 0.800 0.000 0.800 -
Subtotal
50.385 11.839 8.945 11.846 - 11.846 Continuing Continuing N/A
Remarks
Since FY 2020 President's Budget request, FY20 funding was realigned from Support to Product Development to execute critical Lockheed Martin Milestone C Planning efforts
and Engineering Development Model (EDM) assembly, integration and test.
Test and Evaluation ($ in Millions)
FY 2019 FY 2020
FY 2021
Base
FY 2021
OCO
FY 2021
Total
Cost Category Item
Contract
Method
& Type
Performing
Activity & Location
Prior
Years Cost
Award
Date Cost
Award
Date Cost
Award
Date Cost
Award
Date Cost
Cost To
Complete
Total
Cost
Target
Value of
Contract
Test Planning and
Development Testing
WR
NRL : Washington,
DC
4.387 0.164 Jan 2019 2.625 Nov 2019 1.926 Nov 2020 - 1.926 Continuing Continuing Continuing
Volume 3 - 1231
UNCLASSIFIED
PE 0604757N: Ship Self Def (Engage: Soft Kill/EW)
UNCLASSIFIED
Navy Page 26 of 37 R-1 Line #144
Exhibit R-3, RDT&E Project Cost Analysis: PB2021Navy
Date: February 2020
Appropriation/Budget Activity
1319 / 5
R-1 Program Element (Number/Name)
PE 0604757N / Ship Self Def (Engage: Soft
Kill/EW)
Project (Number/Name)
3316 / Advanced Offboard EW
Test and Evaluation ($ in Millions)
FY 2019 FY 2020
FY 2021
Base
FY 2021
OCO
FY 2021
Total
Cost Category Item
Contract
Method
& Type
Performing
Activity & Location
Prior
Years Cost
Award
Date Cost
Award
Date Cost
Award
Date Cost
Award
Date Cost
Cost To
Complete
Total
Cost
Target
Value of
Contract
Test Planning and
Development Testing
WR
NSWC/Dahlgren :
Dahlgren, VA
3.213 0.000 0.600 Dec 2019 0.564 Nov 2020 - 0.564 Continuing Continuing Continuing
Test Planning and
Development Testing
WR
NSWC Crane :
Crane, IN
1.386 0.040 Nov 2018 0.002 Nov 2019 0.200 Nov 2020 - 0.200 Continuing Continuing Continuing
Test Planning and
Development Testing
WR
NAVAIR : Patuxent
River, MD
1.095 1.829 Dec 2018 0.719 Nov 2019 7.191 Nov 2020 - 7.191 Continuing Continuing Continuing
Test Planning and
Development Testing
WR
OPTEVFOR :
Norfolk, VA
0.674 0.000 0.122 Nov 2019 0.122 Nov 2020 - 0.122 Continuing Continuing Continuing
Test Planning and
Development Testing
SS/CPFF APL : Laurel, MD 0.000 0.000 0.000 0.300 Nov 2020 - 0.300 Continuing Continuing Continuing
Subtotal
10.755 2.033 4.068 10.303 - 10.303 Continuing Continuing N/A
Remarks
Since FY 2020 President's Budget request, FY20 funding was realigned from Test and Evaluation to Product Development to execute critical Lockheed Martin Milestone C
Planning efforts and Engineering Development Model (EDM) assembly, integration and test. Funding in FY21 is required to execute critical developmental and NAVAIR Flight
Certification testing.
Management Services ($ in Millions)
FY 2019 FY 2020
FY 2021
Base
FY 2021
OCO
FY 2021
Total
Cost Category Item
Contract
Method
& Type
Performing
Activity & Location
Prior
Years Cost
Award
Date Cost
Award
Date Cost
Award
Date Cost
Award
Date Cost
Cost To
Complete
Total
Cost
Target
Value of
Contract
Program Management
Support
C/CPIF
CACI (SEAPORT) :
Washington, DC
1.170 0.000 0.000 0.000 - 0.000 0.000 1.170 -
Program Management
Support
C/CPIF
SPA : Washington,
DC
0.821 0.000 0.000 0.000 - 0.000 0.000 0.821 -
Program Management
Support
C/CPIF
TMB (SEAPORT) :
Washington, DC
1.693 0.000 0.000 0.000 - 0.000 0.000 1.693 -
Program Management
Support
C/CPIF
STRATEGIC
INSIGHT
(SEAPORT) :
Washington, DC
0.058 0.000 0.000 0.000 - 0.000 0.000 0.058 -
Program Management
Support
WR
NSWC Indian Head :
Indian Head, MD
0.053 0.000 0.000 0.000 - 0.000 0.000 0.053 -
Volume 3 - 1232
UNCLASSIFIED
PE 0604757N: Ship Self Def (Engage: Soft Kill/EW)
UNCLASSIFIED
Navy Page 27 of 37 R-1 Line #144
Exhibit R-3, RDT&E Project Cost Analysis: PB2021Navy
Date: February 2020
Appropriation/Budget Activity
1319 / 5
R-1 Program Element (Number/Name)
PE 0604757N / Ship Self Def (Engage: Soft
Kill/EW)
Project (Number/Name)
3316 / Advanced Offboard EW
Management Services ($ in Millions)
FY 2019 FY 2020
FY 2021
Base
FY 2021
OCO
FY 2021
Total
Cost Category Item
Contract
Method
& Type
Performing
Activity & Location
Prior
Years Cost
Award
Date Cost
Award
Date Cost
Award
Date Cost
Award
Date Cost
Cost To
Complete
Total
Cost
Target
Value of
Contract
Travel Allot
NAVSEA Program
Office Travel :
Washington, DC
0.189 0.032 Dec 2018 0.040 Nov 2019 0.040 Nov 2020 - 0.040 Continuing Continuing Continuing
Cost Management Support C/CPIF
CACI (SEAPORT) :
Washington, DC
0.000 0.000 0.120 Nov 2019 0.000 - 0.000 0.000 0.120 -
Subtotal
3.984 0.032 0.160 0.040 - 0.040 Continuing Continuing N/A
Remarks
Since FY 2020 President's Budget request, FY20 funding was realigned from Management Services to Product Development to execute critical Lockheed Martin Milestone C
Planning efforts and Engineering Development Model (EDM) assembly, integration and test.
Prior
Years FY 2019 FY 2020
FY 2021
Base
FY 2021
OCO
FY 2021
Total
Cost To
Complete
Total
Cost
Target
Value of
Contract
Project Cost Totals
160.758 70.691 52.198 44.814 - 44.814 Continuing Continuing N/A
Remarks
Volume 3 - 1233
UNCLASSIFIED
PE 0604757N: Ship Self Def (Engage: Soft Kill/EW)
UNCLASSIFIED
Navy Page 28 of 37 R-1 Line #144
Exhibit R-4, RDT&E Schedule Profile: PB2021Navy
Date: February 2020
Appropriation/Budget Activity
1319 / 5
R-1 Program Element (Number/Name)
PE 0604757N / Ship Self Def (Engage: Soft
Kill/EW)
Project (Number/Name)
3316 / Advanced Offboard EW
Volume 3 - 1234
UNCLASSIFIED
PE 0604757N: Ship Self Def (Engage: Soft Kill/EW)
UNCLASSIFIED
Navy Page 29 of 37 R-1 Line #144
Exhibit R-4A, RDT&E Schedule Details: PB2021Navy
Date: February 2020
Appropriation/Budget Activity
1319 / 5
R-1 Program Element (Number/Name)
PE 0604757N / Ship Self Def (Engage: Soft
Kill/EW)
Project (Number/Name)
3316 / Advanced Offboard EW
Schedule Details
Start End
Events by Sub Project Quarter Year Quarter Year
Proj 3316
DDE / E&MD 1 2019 2 2021
MH60-R/S Flight Certification 2 2019 3 2021
DDE Test and Certification 2 2019 1 2022
Developmental Test (DT) Assist 2 2020 2 2020
Milestone (MS) C / LRIP DR 3 2020 3 2020
Initial Operational Test and Evaluation (IOT&E) 1 2022 1 2022
Autonomous Flight Vehicle Requirements Definition 1 2022 4 2025
Full Rate Production (FRP) / Decision Review (DR) 2 2022 2 2022
Follow-On Operational Test and Evaluation (FOT&E) 3 2023 3 2023
Volume 3 - 1235
UNCLASSIFIED
PE 0604757N: Ship Self Def (Engage: Soft Kill/EW)
UNCLASSIFIED
Navy Page 30 of 37 R-1 Line #144
Exhibit R-2A, RDT&E Project Justification: PB2021Navy
Date: February 2020
Appropriation/Budget Activity
1319 / 5
R-1 Program Element (Number/Name)
PE 0604757N / Ship Self Def (Engage: Soft
Kill/EW)
Project (Number/Name)
3321 / SEWIP Block 3
COST ($ in Millions)
Prior
Years FY 2019 FY 2020
FY 2021
Base
FY 2021
OCO
FY 2021
Total FY 2022 FY 2023 FY 2024 FY 2025
Cost To
Complete
Total
Cost
3321: SEWIP Block 3
326.590 39.360 22.129 22.893 - 22.893 6.903 6.947 7.078 7.221 Continuing Continuing
Quantity of RDT&E Articles - - - - - - - - -
A. Mission Description and Budget Item Justification
SEWIP Block 3 is developing an Electronic Attack (EA) capability to improve Anti-Ship Missile Defense (ASMD) and counter-targeting required for the AN/SLQ-32(V)
system to keep pace with the threat. SEWIP Block 3 will provide the AN/SLQ-32(V)7 system for all surface ships (CVN, DDG, LHD) outfitted with the active variant of
the AN/SLQ-32, mainly the (V)3 and (V)4, as well as select new construction platforms.
The SEWIP Block 3 Acquisition leverages technology developed under the Office of Naval Research's (ONR) Integrated Topside (InTop) Science and Technology
(S&T) effort. SEWIP Block 3 will continue to expand the integrated shipboard combat system by providing new integrated EA transmitters, arrays, and associated EA
techniques. The AN/SLQ-32(V)7 integrates the new EA countermeasure (SEWIP Block 3) with the AN/SLQ-32(V)6. The AN/SLQ-32(V)6 includes an Electronic Support
(ES) receiver (SEWIP Block 2), a High Gain High Sensitivity (HGHS) receiver (SEWIP Block 1B3), a Specific Emitter Identifier (SEI) receiver (SEWIP Block 1B2), display
console, and backend electronics. SEWIP Block 3 includes the government software development and integration effort for a SoftKill Coordinator (SKC) to manage EA
engagements. SEWIP Block 3 is developing an Electronic Warfare Test Bed (EWTB) to validate system performance via modeling and simulation.
B. Accomplishments/Planned Programs ($ in Millions, Article Quantities in Each)
FY 2019 FY 2020
FY 2021
Base
FY 2021
OCO
FY 2021
Total
Title: SEWIP Block 3 Government Engineering
Articles:
FY 2020 Plans:
- Complete support of Engineering Development Model (EDM) hardware and software development and
integration.
- Complete support of FQT.
- Accept EDM delivery.
- Commence support of Land Based test events at Wallops Island.
- Continue EWTB model development and verification/validation of model performance.
- Continue integrated topside design activities with DDG, CVN and LHD.
- Continue test planning for IOT&E.
- Continue planning & development of training curriculum.
- Continue to support platform integration activities to ensure compatibility with Aegis and SSDS Combat
Systems.
- Support System Verification Review/Functional Configuration Audit (SVR/FCA).
5.418
-
7.325
-
12.062
-
0.000
-
12.062
-
Volume 3 - 1236
UNCLASSIFIED
PE 0604757N: Ship Self Def (Engage: Soft Kill/EW)
UNCLASSIFIED
Navy Page 31 of 37 R-1 Line #144
Exhibit R-2A, RDT&E Project Justification: PB2021Navy
Date: February 2020
Appropriation/Budget Activity
1319 / 5
R-1 Program Element (Number/Name)
PE 0604757N / Ship Self Def (Engage: Soft
Kill/EW)
Project (Number/Name)
3321 / SEWIP Block 3
B. Accomplishments/Planned Programs ($ in Millions, Article Quantities in Each)
FY 2019 FY 2020
FY 2021
Base
FY 2021
OCO
FY 2021
Total
- Complete development of test asset development and procurement.
- Commence monitoring of software and hardware baseline upgrades.
FY 2021 Base Plans:
- Continue support of Land Based test events at Wallops Island.
- Continue EWTB model development and verification/validation of model performance.
- Continue integrated topside design activities with DDG, CVN and LHD.
- Continue test planning for IOT&E.
- Continue planning & development of training curriculum.
- Continue to support platform integration activities to ensure compatibility with Aegis and SSDS Combat
Systems.
- Continue monitoring of SW & HW fixes/upgrades.
FY 2021 OCO Plans:
N/A
FY 2020 to FY 2021 Increase/Decrease Statement:
- Increase in FY 2021 is due to the conduct of Government testing with the Engineering Development Model
(EDM) at Wallops Island Land Based Test (LBT) facility.
Title: SEWIP Block 3 Development
Articles:
FY 2020 Plans:
- Complete E&MD which includes completion of EDM hardware and software development and integration.
- Conduct SVR/FCA and complete FQT.
- Deliver the EDM.
- Commence support of Land Based test events at Wallops Island.
- Continue support for model and simulation development for EWTB.
- Complete integrated topside design activities with DDGs.
- Complete platform integration activities to ensure compatibility with Aegis Combat Systems.
- Continue Surface Electronic Warfare Team Trainer (SEWTT) EA functionality development for AN/SLQ-32(V).
- Commence upgrades of software and hardware baseline based on LBT results.
FY 2021 Base Plans:
- Continue upgrades of software and hardware baseline based on LBT results.
33.942
-
14.804
-
10.831
-
0.000
-
10.831
-
Volume 3 - 1237
UNCLASSIFIED
PE 0604757N: Ship Self Def (Engage: Soft Kill/EW)
UNCLASSIFIED
Navy Page 32 of 37 R-1 Line #144
Exhibit R-2A, RDT&E Project Justification: PB2021Navy
Date: February 2020
Appropriation/Budget Activity
1319 / 5
R-1 Program Element (Number/Name)
PE 0604757N / Ship Self Def (Engage: Soft
Kill/EW)
Project (Number/Name)
3321 / SEWIP Block 3
B. Accomplishments/Planned Programs ($ in Millions, Article Quantities in Each)
FY 2019 FY 2020
FY 2021
Base
FY 2021
OCO
FY 2021
Total
- Continue SEWTT EA functionality development for AN/SLQ-32(7)(EWA).
- Continue support of Land Based test events at Wallops.
- Continue support for model and simulation development for EWTB.
FY 2021 OCO Plans:
N/A
FY 2020 to FY 2021 Increase/Decrease Statement:
- Decrease in FY2021 is due to the completion of E&MD in FY2020.
Accomplishments/Planned Programs Subtotals
39.360 22.129 22.893 0.000 22.893
C. Other Program Funding Summary ($ in Millions)
Line Item FY 2019 FY 2020
FY 2021
Base
FY 2021
OCO
FY 2021
Total FY 2022 FY 2023 FY 2024 FY 2025
Cost To
Complete Total Cost
• OPN/2312: AN/SLQ-32 352.677 340.706 387.195 - 387.195 417.015 404.848 345.809 349.898 2,339.367 6,194.706
Remarks
D. Acquisition Strategy
SEWIP will develop block upgrades to SLQ-32 based on integrating technology advances and adding functional capabilities in an incremental fashion. Each block
and sub-block will be developed and contracted in an individual yet coordinated and overlapping fashion. Specifically, SEWIP Block 3 involves the transitioning and
leveraging of work performed under the Integrated Topside (INTOP) program sponsored by ONR, which focused on designing/architecting an integrated Electronic
Attack (EA), Information Operations (IO), and Line of Site (LOS) Comms system for Naval Surface Platforms.
Volume 3 - 1238
UNCLASSIFIED
PE 0604757N: Ship Self Def (Engage: Soft Kill/EW)
UNCLASSIFIED
Navy Page 33 of 37 R-1 Line #144
Exhibit R-3, RDT&E Project Cost Analysis: PB2021Navy
Date: February 2020
Appropriation/Budget Activity
1319 / 5
R-1 Program Element (Number/Name)
PE 0604757N / Ship Self Def (Engage: Soft
Kill/EW)
Project (Number/Name)
3321 / SEWIP Block 3
Product Development ($ in Millions)
FY 2019 FY 2020
FY 2021
Base
FY 2021
OCO
FY 2021
Total
Cost Category Item
Contract
Method
& Type
Performing
Activity & Location
Prior
Years Cost
Award
Date Cost
Award
Date Cost
Award
Date Cost
Award
Date Cost
Cost To
Complete
Total
Cost
Target
Value of
Contract
Block 3 SEWTT
Development
SS/CPFF
EWA-GSI : Fairmont,
WV
1.619 0.000 Dec 2018 0.150 Apr 2020 0.225 Dec 2020 - 0.225 Continuing Continuing Continuing
Block 3 Preliminary
Design/E&MD
C/CPIF
Northrop Grumman :
Baltimore, MD
210.897 33.942 Oct 2018 14.654 Oct 2019 10.606 Oct 2020 - 10.606 Continuing Continuing Continuing
Subtotal
212.516 33.942 14.804 10.831 - 10.831 Continuing Continuing N/A
Remarks
FY2019 SEWIP Block 3 Development funding increased since FY 2020 President's Budget Request. $4.182M realigned from SEWIP Block 1 RCIP due to increased EMD
Integration & Test complexity. Additionally, $3.376M re-allocated from Government Engineering due to realization of technical assumptions in the Original Equipment
Manufacturer's (OEM) original proposal related to hardware ruggedization and software complexity.
Support ($ in Millions)
FY 2019 FY 2020
FY 2021
Base
FY 2021
OCO
FY 2021
Total
Cost Category Item
Contract
Method
& Type
Performing
Activity & Location
Prior
Years Cost
Award
Date Cost
Award
Date Cost
Award
Date Cost
Award
Date Cost
Cost To
Complete
Total
Cost
Target
Value of
Contract
Block 3 Integrated
Logistics Support
WR
NSWC Crane :
Crane, IN
9.698 0.018 Nov 2018 0.000 0.000 - 0.000 0.000 9.716 Continuing
Block 3 Integrated
Logistics Support
WR
NSWC Corona :
Corona, CA
0.023 0.000 0.000 0.000 - 0.000 0.000 0.023 -
Block 3 Government
Engineering Support
WR
NSWC Dahlgren :
Dahlgren, VA
22.453 0.277 Nov 2018 0.382 Nov 2019 0.200 Nov 2020 - 0.200 Continuing Continuing Continuing
Block 3 Government
Engineering Support
WR
NSWC Crane :
Crane, IN
8.329 0.243 Nov 2018 0.344 Nov 2019 0.255 Nov 2020 - 0.255 Continuing Continuing Continuing
Block 3 Government
Engineering Support
WR
NRL : Washington,
DC
21.238 1.002 Dec 2018 0.806 Nov 2019 0.395 Nov 2020 - 0.395 Continuing Continuing Continuing
Block 3 Government
Engineering Support
SS/CPFF APL : Laurel, MD 24.540 0.299 Dec 2018 0.293 Nov 2019 0.150 Nov 2020 - 0.150 Continuing Continuing Continuing
Block 3 Government
Engineering Support
WR
MIT-LL : Cambridge,
MA
4.794 0.000 0.000 0.000 - 0.000 0.000 4.794 Continuing
Block 3 Feasibility Studies WR BIW : Bath, ME 0.510 0.000 0.000 0.000 - 0.000 0.000 0.510 -
Volume 3 - 1239
UNCLASSIFIED
PE 0604757N: Ship Self Def (Engage: Soft Kill/EW)
UNCLASSIFIED
Navy Page 34 of 37 R-1 Line #144
Exhibit R-3, RDT&E Project Cost Analysis: PB2021Navy
Date: February 2020
Appropriation/Budget Activity
1319 / 5
R-1 Program Element (Number/Name)
PE 0604757N / Ship Self Def (Engage: Soft
Kill/EW)
Project (Number/Name)
3321 / SEWIP Block 3
Support ($ in Millions)
FY 2019 FY 2020
FY 2021
Base
FY 2021
OCO
FY 2021
Total
Cost Category Item
Contract
Method
& Type
Performing
Activity & Location
Prior
Years Cost
Award
Date Cost
Award
Date Cost
Award
Date Cost
Award
Date Cost
Cost To
Complete
Total
Cost
Target
Value of
Contract
Block 3 Platform
Integration Studies
WR
Norfolk Naval
Shipyard (NNSY) :
Norfolk, VA
0.040 0.000 0.000 0.000 - 0.000 0.000 0.040 -
Block 3 Platform
Integration Studies
WR
SUPSHIP Gulf
Coast : Pascagoula,
MS
0.062 0.000 0.000 0.000 - 0.000 0.000 0.062 -
Block 3 Platform
Integration Studies
WR
NSWC Philadelphia :
Philadelphia, PA
0.212 0.000 0.000 0.000 - 0.000 0.000 0.212 -
Block 3 Platform
Integration Studies
WR
NAVSEA 05 (Alion) :
Washington, DC
0.297 0.000 0.000 0.000 - 0.000 0.000 0.297 -
Block 3 Platform
Integration Studies
WR
NAVSEA
05 (CSRA) :
Washington, DC
0.149 0.000 0.000 0.000 - 0.000 0.000 0.149 -
Block 3 Platform
Integration Studies
WR
Lockheed Martin :
Moorstown, NJ
0.202 0.000 0.000 0.000 - 0.000 0.000 0.202 -
Subtotal
92.547 1.839 1.825 1.000 - 1.000 Continuing Continuing N/A
Test and Evaluation ($ in Millions)
FY 2019 FY 2020
FY 2021
Base
FY 2021
OCO
FY 2021
Total
Cost Category Item
Contract
Method
& Type
Performing
Activity & Location
Prior
Years Cost
Award
Date Cost
Award
Date Cost
Award
Date Cost
Award
Date Cost
Cost To
Complete
Total
Cost
Target
Value of
Contract
Block 3 Test Planning/T&E
Events
WR
NSWC Dahlgren :
Dahlgren, VA
4.329 0.010 Nov 2018 0.685 Nov 2019 1.160 Nov 2020 - 1.160 Continuing Continuing Continuing
Block 3 Test Planning/T&E
Events
WR
NSWC Crane :
Crane, IN
2.603 0.015 Nov 2018 0.650 Nov 2019 1.160 Nov 2020 - 1.160 Continuing Continuing Continuing
Block 3 Test Planning/T&E
Events
WR
NRL : Washington,
DC
10.149 0.850 Dec 2018 1.673 Nov 2019 5.017 Nov 2020 - 5.017 Continuing Continuing Continuing
Block 3 Test Planning/T&E
Events
SS/CPFF APL : Laurel, MD 0.772 0.320 Jan 2019 0.390 Nov 2019 1.080 Nov 2020 - 1.080 Continuing Continuing Continuing
Block 3 Test Planning/T&E
Events
WR
COMOPTEVFOR :
Norfolk, VA
0.267 0.107 Dec 2018 0.200 Nov 2019 0.450 Nov 2020 - 0.450 Continuing Continuing Continuing
Volume 3 - 1240
UNCLASSIFIED
PE 0604757N: Ship Self Def (Engage: Soft Kill/EW)
UNCLASSIFIED
Navy Page 35 of 37 R-1 Line #144
Exhibit R-3, RDT&E Project Cost Analysis: PB2021Navy
Date: February 2020
Appropriation/Budget Activity
1319 / 5
R-1 Program Element (Number/Name)
PE 0604757N / Ship Self Def (Engage: Soft
Kill/EW)
Project (Number/Name)
3321 / SEWIP Block 3
Test and Evaluation ($ in Millions)
FY 2019 FY 2020
FY 2021
Base
FY 2021
OCO
FY 2021
Total
Cost Category Item
Contract
Method
& Type
Performing
Activity & Location
Prior
Years Cost
Award
Date Cost
Award
Date Cost
Award
Date Cost
Award
Date Cost
Cost To
Complete
Total
Cost
Target
Value of
Contract
Block 3 Test Planning/T&E
Events
WR
Surface Combat
Systems Center :
Wallops Island, VA
0.356 1.737 Nov 2018 1.544 Nov 2019 1.827 Nov 2020 - 1.827 Continuing Continuing Continuing
Block 3 Test Planning/T&E
Events
WR
USACE (DREN) :
Wallops Island, VA
0.690 0.076 Jun 2019 0.083 Nov 2019 0.088 Nov 2020 - 0.088 Continuing Continuing Continuing
NAVFAC WR
NAVFAC Mid-
Atlantic : Norfolk, VA
0.000 0.192 Nov 2018 0.000 0.000 - 0.000 0.000 0.192 -
Subtotal
19.166 3.307 5.225 10.782 - 10.782 Continuing Continuing N/A
Management Services ($ in Millions)
FY 2019 FY 2020
FY 2021
Base
FY 2021
OCO
FY 2021
Total
Cost Category Item
Contract
Method
& Type
Performing
Activity & Location
Prior
Years Cost
Award
Date Cost
Award
Date Cost
Award
Date Cost
Award
Date Cost
Cost To
Complete
Total
Cost
Target
Value of
Contract
Block 3 Program
Management Support
C/CPIF
TMB (SEAPORT) :
Washington, DC
1.431 0.040 Jan 2019 0.070 Nov 2019 0.070 Nov 2020 - 0.070 Continuing Continuing Continuing
Block 3 Program
Management Support
C/CPIF
CACI (SEAPORT) :
Washington, DC
0.422 0.127 Jan 2019 0.100 Nov 2019 0.100 Nov 2020 - 0.100 Continuing Continuing Continuing
Block 3 Program
Management Support
C/CPIF
SPA : Washington,
DC
0.146 0.055 Dec 2018 0.055 Nov 2019 0.060 Nov 2020 - 0.060 Continuing Continuing Continuing
Block 3 Travel Sub Allot
NAVSEA Program
Office : Washington,
DC
0.362 0.050 Dec 2018 0.050 Nov 2019 0.050 Nov 2020 - 0.050 Continuing Continuing Continuing
Subtotal
2.361 0.272 0.275 0.280 - 0.280 Continuing Continuing N/A
Prior
Years FY 2019 FY 2020
FY 2021
Base
FY 2021
OCO
FY 2021
Total
Cost To
Complete
Total
Cost
Target
Value of
Contract
Project Cost Totals
326.590 39.360 22.129 22.893 - 22.893 Continuing Continuing N/A
Remarks
Volume 3 - 1241
UNCLASSIFIED
PE 0604757N: Ship Self Def (Engage: Soft Kill/EW)
UNCLASSIFIED
Navy Page 36 of 37 R-1 Line #144
Exhibit R-4, RDT&E Schedule Profile: PB2021Navy
Date: February 2020
Appropriation/Budget Activity
1319 / 5
R-1 Program Element (Number/Name)
PE 0604757N / Ship Self Def (Engage: Soft
Kill/EW)
Project (Number/Name)
3321 / SEWIP Block 3
Volume 3 - 1242
UNCLASSIFIED
PE 0604757N: Ship Self Def (Engage: Soft Kill/EW)
UNCLASSIFIED
Navy Page 37 of 37 R-1 Line #144
Exhibit R-4A, RDT&E Schedule Details: PB2021Navy
Date: February 2020
Appropriation/Budget Activity
1319 / 5
R-1 Program Element (Number/Name)
PE 0604757N / Ship Self Def (Engage: Soft
Kill/EW)
Project (Number/Name)
3321 / SEWIP Block 3
Schedule Details
Start End
Events by Sub Project Quarter Year Quarter Year
Proj 3321.L24
Block 3 Engineering and Manufacturing Development (E&MD) 1 2019 3 2020
EW Testbed 1 2019 4 2025
Test Asset Development and Procurement 1 2019 4 2021
Block 3 MS C/LRIP DR 1 2019 1 2019
IT-FQT 1 2019 3 2020
IT-DT 3 2020 2 2022
Software and Hardware Baseline Upgrades 3 2020 4 2025
AMOD DDG (Test Ship) 2 2021 4 2022
AMOD DDG 3 2022 4 2023
Block 3 TECHEVAL and IOT&E 4 2022 1 2023
Block 3 FRP DR 3 2023 3 2023
Block 3 FOT&E 3 2024 3 2024
Volume 3 - 1243
UNCLASSIFIED
THIS PAGE INTENTIONALLY LEFT BLANK
UNCLASSIFIED
Volume 3 - 1244
